PL-05N PL 05N DC 10-30V 5mm NPN NO Proximity Sensor OC10

Inductive Proximity Sensor PL-05N NPN Limit Switch is used for controlling machinery as part of a control system, as a safety interlock, or to count objects passing a point. A limit switch is an electromechanical device that consists of an actuator mechanically linked to a set of contacts. When an object comes into contact with the actuator, the device operates the contacts to make or break an electrical connection. Being an inductive switch, no physical contact is required between the switch and the metallic surface being sensed.
Sensing distance: 5mm
Operating voltage: DC10-30V
Response frequency: 800Hz
Output method : NPN, 150mA load
Hysteresis: Protection degree: IP67
Working temperature/Hum : -20 ~+80C, 35%~90%RH
Body dimension : 30.5 x 17.9 x 10.2mm, LxWxH
Mounting Method: Flush
Sensing Direction: Horizontal
Material Housing: High-impact plastic
Screw hole : 3.2mm, Pitch : 10.5mm
Wire length : 100cm (39-inch)
