E2E-S05S12-WC-C2 E2E S05S12 WC C2 M5 inductive Proximity sensor SD29

E2E-S05S12-WC-C2 E2E S05S12 WC C2 M5 inductive Proximity sensor SD29

Description:
Shielded, Cylinder type (with screw) M5, DC Three-wires models, Sensing distance 1.2 mm ±10%, NC, NPN open collector, Pre-wired models

Feature:
Sensing head size M5
Type Cylinder type (with screw), Shielded
Power source DC Three-wires models
Sensing distance 1.2 mm ±10%
Setting distance 0 to 0.84 mm
Differential distance 15% max. of sensing distance
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object Iron 4 x 4 x 1 mm
Response frequency 4 kHz
Power supply voltage 10 to 30 VDC ripple (p-p) 10% included
Operating voltage range 10 to 30 VDC
Current consumption 10 mA max.
Control output (Output type) NPN open collector
Control output (Switching capacity) 100 mA max.
Control output (Residual voltage) 2 V max. (Load current 100 mA with cable length of 2 m)
Indicator Operation indicator (yellow)
Operation mode NC

Protective circuit:
Output short-cut protection
Output reverse polarity protection
Power supply reverse polarity protection
Surge suppressor
