6 Axis MACH3 Wireless Handwheel CNC MPG Hand wheel KB05

6 Axis MACH3 Wireless Handwheel CNC MPG Hand wheel KB05

Feature:
1.Auto Frequency Hopping When Noise.
Frequency band:433Mhz,ISM ,the output power up to10DB,High receiver sensitivity-98DB.
32 hopping channels, the channel frequency gap is 1Mhz.
the transmission is encrypted, auto builds communication network and pair. auto hopping when noise.
32 sets of wireless MPG could be used at the same time in one room.
2. LCD display
Display the X Y Z A B C axis work and machine coordinate data.
Display the spindle and feed speed.
The LCD display data with background light.
3. Axis/Step band switch
To choose X/Y/Z/A/B/C axis or close all axis by axis switch, to choose jog step by step switch.
4. support 10 macro function button

SPEK:
Maximum axis:6 axis
Parameter:Description
Frequency bands:ISM,433MHZ
Supply voltage:2 AA batteries
MPG Encoder:100PPR
Function Key:16 Keys(support 10 macro function button)
Output power:10DB
Receiver sensitivity: -98DB
LCD:Dot LCD with background light
