NBN40-U1L-UU NBN40 U1L UU Inductive sensor PZ30

NBN40-U1L-UU NBN40 U1L UU Inductive sensor PZ30

Feature:
Operating voltage indicator LED, green
Degree of protection IP67
Hysteresis 1 … 10 typ. 5 %
Reverse polarity protection reverse polarity tolerant
Assured operating distance 0 … 32.4 mm
CCC approval Ue 75VDC – 250VDC Ue 75VAC – 230VAC
Output type Two-wire
Rated operating distance 40 mm
Housing base plastic
Output type 2-wire
Installation non-flush
Switching state indicator LED, yellow
Voltage drop 5 V (typ. 2V) DC operation
8 V (typ. 2V) AC operation
Connection type terminal compartment
Switching function Normally open/closed (NO/NC)
Momentary current
(20 ms, 0.1 Hz) 0 … 3000 mA
UL approval cULus Listed, General Purpose
“”For use in NFPA 79 Applications only””
For overcurrent protection, install a fuse with a rated current of max. 3 A and at least 300 V AC/DC
Operating voltage 20 … 300 V DC / 20 … 253 V AC
Reduction factor rAl 0.37
Short-circuit protection pulsing
Reduction factor rBrass 0.4
Operating current 5 … 500 mA
Ambient temperature -25 … 85 В°C (-13 … 185 В°F)
Housing material PA 6.6 / metal
Switching frequency 0 … 25 Hz
Time delay before availability 300 ms
Storage temperature -25 … 85 В°C (-13 … 185 В°F)
Error indicator flashes when overcurrent
Rated operating voltage 24 … 250 V DC / 24 … 230 V AC
Protection class II
Core cross-section up to 2.5 mm2
Reduction factor rCu 0.3
Output polarity AC/DC
Reduction factor rFe 1
Off-state current 1.5 mA
