M18 5m E3F-5DN1 E3F-5L NPN NO through beam photoelectric sensor OA65

M18 5m E3F-5DN1 E3F-5L NPN NO through beam photoelectric sensor OA65

Description:
M18 5m sensing DC NPN NO E3F-5DN1 E3F-5L through beam cylinder amplifier photoelectric sensor

Feature:
Brand: DAPPRA
External dimensions M18x1x67.5
Sensing method Through beam
Detection distance 5m±10%
Sensitivity adjustment Fixed
Supply voltage 6-36Vdc; 90-250Vac 50/60Hz
Rated output current N.P Type: 300mA max; A Type: 400mA; J type: 2A max (contact life: 100000 times)
Sensing object Opaque object
Response frequency 300Hz
Response time 1.5ms max
Light source Infrared LED (660 nm)
Leakage current N.P Type: 20mA max; A Type: 1.7mA max
Protection circuit DC: Reverse connection protection, Surge suppressor, Short-circuit protection
