E2E2-X5C1 E2E2 X5C1 E2E2X5C1 M18 2M NPN NO Inductive Proximity PO61

E2E2-X5C1 E2E2 X5C1 E2E2X5C1 M18 2M NPN NO Inductive Proximity PO61

Description:
Shielded, Cylinder type (with screw) M18, DC Three-wires models, Sensing distance 5 mm ±10%, NO, NPN open collector, Pre-wired models

Feature:
Sensing head size M18
Type Cylinder type (with screw), Shielded
Power source DC Three-wires models
Sensing distance 5 mm ±10%
Setting distance 0 to 4 mm
Differential distance 10% max. of sensing distance
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object Iron 18 x 18 x 1 mm
Response frequency 600 Hz (Average value)
Power supply voltage 12 to 24 VDC ripple (p-p) 10% max.
Operating voltage range 10 to 30 VDC
Current consumption 13 mA max.
Control output (Output type) NPN open collector
Control output (Switching capacity) 200 mA max. (30 VDC max.)
Control output (Residual voltage) 2 V max. (Load current 200 mA with cable length of 2 m)
Indicator Operation indicator (red)
Operation mode NO
Protective circuit Output short-cut protection
Power supply reverse polarity protection
Surge suppressor
