E2E-X3D2-M1G E2E X3D2 M1G M12 NC inductive Proximity Sensor PW61

E2E-X3D2-M1G E2E X3D2 M1G M12 NC inductive Proximity Sensor PW61

Description:
Shielded, Cylinder type (with screw) M12, DC 2-wire models, Sensing distance 3 mm ±10%, NC, Polarity, M12 connector models (IEC pin arrangement)

Feature:
Sensing head size M12
Type Cylinder type (with screw), Shielded
Power source DC 2-wire models
Sensing distance 3 mm ±10%
Setting distance 0 to 2.4 mm
Differential distance 10% max. of sensing distance
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object Iron 12 x 12 x 1 mm
Response frequency 1 kHz
Power supply voltage 12 to 24 VDC ripple (p-p) 10% max.
Operating voltage range 10 to 30 VDC
Used as UL-certified Models: 12 to 24 VDC
Leakage current 0.8 mA max.
Control output (Switching capacity) 3 to 100 mA
Indicator Operation indicator (red)
Operation mode NC
Polarity Polarity
Protective circuit Output short-cut protection Surge suppressor
