E2E-C03SR8-WC-B1 2M DC PNP NO Small-diameter Proximity Sensor SE25

E2E-C03SR8-WC-B1 2M DC PNP NO Small-diameter Proximity Sensor SE25

Description:
Shielded, Cylinder type 3 dia., DC Three-wires models, Sensing distance 0.8 mm ±10%, NO, PNP open collector, Pre-wired models

Feature:
Sensing head size 3 dia.
Type Cylinder type, Shielded
Power source DC Three-wires models
Sensing distance 0.8 mm ±10%
Setting distance 0 to 0.56 mm
Differential distance 15% max. of sensing distance
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object Iron 3 x 3 x 1 mm
Response frequency 5 kHz
Power supply voltage 10 to 30 VDC ripple (p-p) 10% included
Operating voltage range 10 to 30 VDC
Current consumption 10 mA max.
Control output (Output type) PNP open collector
Control output (Switching capacity) 50 mA max.
Control output (Residual voltage) 2 V max. (Load current 50 mA with cable length of 2 m)
Indicator Operation indicator (yellow)
Operation mode NO
Protective circuit Output short-cut protection
Output reverse polarity protection
Power supply reverse polarity protection
Surge suppressor
