E2A-S08LN04-M1-B1 E2A – S08LN04 – M1 – B1 PNP NO Proximity sensor PU08

E2A-S08LN04-M1-B1 E2A – S08LN04 – M1 – B1 PNP NO Proximity sensor PU08

Desciption:
Proximity sensor, inductive, stainless steel, long body, M8, non-shielded, 4mm, DC, 3-wire, PNP-NO, M12 connector
The E2A-S08LN04-M1-B1 OMC from Omron Industrial Automation is an E2A series cylindrical proximity sensor. It has a safe mounting with greater sensing distance approximately 1.5 to 2 times larger than that of any conventional Omron sensor. This cylindrical proximity sensor uses high-frequency oscillations. It resists heat, chemicals and water better than rectangular sensors.

Feature:
Size M8
Mounting type Non-flush
Sensing distance 4 mm
Output type PNP
Operation mode NO
Connection method Connector M12
Material housing Stainless steel
Cable specifications –
Overall length 65 mm
Thread length 43 mm
Standard, M8, long barrel, non-shielded sensor
Cylindrical, metric threaded, stainless steel housing
Sensing distance is 4mm
M12 connector (4 pole) connection
DC power source, 3 wire, PNP open collector output
Operating mode is normally open (NO)
Power supply voltage range from 12VDC to 24VDC
Yellow LED for indication
Insulation resistance is 50Mohm min at 500VDC, dielectric strength is 1000VAC at 50/60Hz
Approved by IEC60529, EN60947-5-2 standards, water resistance IP67

SPEK:
Sensing Range Max: 4mm
Thread Size – Metric: M8
Sensor Output: PNP
Supply Voltage DC Min: 12V
Supply Voltage DC Max: 24V
Product Range: E2A Series

Applications
Sensing & Instrumentation, Industrial
