S18SN6DL S18 EPOXY ENCAPSULATED Diffuse Optical Sensor SC16

S18SN6DL S18 EPOXY ENCAPSULATED Diffuse Optical Sensor SC16

Feature:
Sensing Beam Infrared LED
Cable Length (m) 2
Power DC
Sensing Mode (General) Proximity
Sensing Mode (Detailed) Diffuse
Housing Style Barrel
Primary Housing Material Thermoplastic
Input/Output Discrete
Max Sensing Distance (mm) 300
Outputs NPN
Power Supply/Supply Voltage 10-30 V dc
Connection Cable
Quick Disconnect Type No QD
Min Op. Temp. (°C) -40
Operation Light/Dark Operate
Max Op. Temp. (°C) 70
Output response time (ms) 3
Special Feature: Intrinsically Safe No
Special Feature: Remote Teach No
Special Feature: Water Detection No
Delay at Power-up (ms) 100
Repeatability (?s) 750
Number of Pins 4
