QS18EN6LP 3500mm NPN 4PIN All Purpose Photoelectric Sensor ST72

QS18EN6LP 3500mm NPN 4PIN All Purpose Photoelectric Sensor ST72

Feature:
Sensing Mode (General) Retroreflective
Sensing Mode (Detailed) Polarized
Housing Style Rectangular w/ M18 Mount
Primary Housing Material Thermoplastic
Input/Output Discrete
Max Sensing Distance 3500 mm
Outputs NPN
Power Supply/Supply Voltage 10 to 30 VDC
Connection 2 m Cable
Quick Disconnect Type No QD
Sensing Beam Visible Red LED
Operation Light/Dark Operate
Max Operating Temperature 70 deg C (158 deg F)
Min Operating Temperature -20 deg C (-4 deg F)
Output Response Time 0.6 ms
Special Feature: Intrinsically Safe No
Special Feature: Remote Teach Yes
Special Feature: Water Detection No
IP Rating IP67
Delay at Power-up 100 ms
Repeatability 75 microseconds
Number of Pins 4 Pin
NEMA Rating NEMA 6
Max Op. Relative Humidity (%) 95% @ 50 deg C
Lens Material Polymethylmethacrylate (PMMA)
Adjustments Teach Button
Barrel Diameter 18 mm
Indicator Display Type LEDs
Feature: Timing (Hold/Delay) Yes
