E3Z-R61K E3Z R61K 2M Photoelectric Sensor with Built-in Amplifier SC83
Rp390,000.00
VOUCHER
Diskon 5% min. belanja Rp1JT
🔥 17 items sold in last 3 jam
24 orang sedang melihat produk ini sekarang
Tanya dulu via WhatsApp
E3Z-R61K E3Z R61K 2M Photoelectric Sensor with Built-in Amplifier SC83
Description:
Retro-reflective with M.S.R. function, Sensing distance When using the E39-R1S: 150 mm to 3 m, Light-ON/Dark-ON selectable, NPN, Pre-wired models (2 m), Red LED (660 nm)
Feature:
Shape Square type
Sensing method Retro-reflective with M.S.R. function
Sensing distance When using the E39-R1S: 150 mm to 3 m
When using the E39-R1: 100 mm to 2 m
Standard sensing object Opaque: 75 mm dia. min.
Directional angle 2 to 10°
Light source Red LED (660 nm)
Power supply voltage 12 to 24 VDC±10% ripple (p-p) 10% max.
Current consumption 30 mA max.
Control output NPN open collector
26.4 VDC max.
100 mA max.
Residual voltage: 1 V max. (Load current Less than 10 mA)
Residual voltage: 2 V max. (Load current 10 to 100 mA)
Operation mode Light-ON/Dark-ON selectable
Protective circuit Output short-circuit protection, Output reverse polarity protection, Power supply reverse polarity protection
Response time Operate or reset: 1 ms max.
Sensitivity setting Single-turn adjustment
Ambient illuminance Incandescent lamp: 3,000 lx max.
Sunlight: 10,000 lx max.
Ambient temperature range (Operating) -25 to 55 ℃ (with no icing)
Ambient temperature range (Storage) -40 to 70 ℃ (with no freezing or condensation)
Ambient humidity range (Operating) 35 to 85% (with no condensation)
Ambient humidity range (Strage) 35 to 95% (with no condensation)
Insulation resistance 20 MΩ min. (500 VDC megger)
Dielectric strength 1000 VAC 50/60 Hz 1 min
Vibration resistance Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h
Shock resistance Destruction: 500 m/s2 3 times each in X, Y and Z directions
Degree of protection IEC: IP67
Company standard: Oil resistance (excluding cables and connectors)
Connection method Pre-wired models (Cable length 2 m)
Indicator Operation indicator (orange), Stability indicator (green)
Weight Package: Approx. 65 g
Accessories Instruction manual
