HF2211 RS232 RS422 RS485 to WiFi Ethernet DTU Device Server PW35
Rp560,000.00
VOUCHER
Diskon 5% min. belanja Rp1JT
🔥 8 items sold in last 3 jam
81 orang sedang melihat produk ini sekarang
Tanya dulu via WhatsApp
HF2211 RS232 RS422 RS485 to WiFi Ethernet DTU Device Server PW35
Description
MIPS MCU with 4MB Flash and 8MB SRAM. Run on eCos
Support TCP/IP/Telnet /Modbus TCP Protocol
Support RS232/RS422/RS485 to Ethernet/Wi-Fi Conversion, Serial Speed Upto 460800 bps
Support STA/AP/AP+STA Mode
Support Router or Bridge Network Working Mode.
Support 10/100M Ethernet Auto-Negotiation
Support Easy Configuration Through a Web Interface or PC IOT Manager Tool
Support Security Protocol Such As SSL/AES/DES3
Support Web OTA Wirelss Upgrade
Wide DC Input 5~36VDC or 9~50VDC
Size: 95 x65x 25 mm(Lx W x H)
FCC/CE/RoHS Certificated
Specification
Processor: MIPS
Basic Frequency: 320MHz
Flash: 4MB
SDRAM: 8MB
Operating System: eCos
Ethernet Interface: 1 x standard RJ45
Rate: 10/100M
Protection: 8KV isolation
Network Protocol: IP，TCP，UDP，DHCP，DNS，HTTP Server/Client，ARP, BOOTP, AutoIP, ICMP，Web socket, Telnet, FTP,TFTP, uPNP, NTP, SNMP,Modbus TCP
Security Protocol: SSL v3 AES 128Bit DES3
Wi-Fi standard: 802.11 b/g/n
Network Mode: STA/AP/STA+AP
Access Terminal Quantity in AP Mode: Max 32
Transmit Power: 802.11b: +20dBm(Max.) 802.11g: +18dBm(Max.) 802.11n: +15dBm(Max.)
Receive Sensitivity: 802.11b: -89dBm 802.11g: -81dBm 802.11n: -71dBm
Wi-Fi Security: WEP64/WEP128/TKIP/ AES
Antenna Interface: 3dBi antenna
Port Number: 1 x RS232/RS485/RS422
Interface Standard: RS232: DB9 RS485/RS422: 5.08mm connector
Data Bits: 8
Stop Bit: 1,2
Check Bit: None, Even, Odd
Baud Rate: TTL: 600 bps~460800bps
Flow Control: No Flow control Hardware RTS/CTS、DSR/DTR Software Xon/ Xoffflow control
Buffer: 4K
Configuration: Web CLI XML import Telnet IOTManagerPC Software
Virtual Serial: Windows, XP/Vista, 7， Server 2003/2008
Size: 95mm x 65mm x 25mm
Operating Temp.: -25 ~ 85°C
Storage Temp.: -45 ~ 105°C，5 ~ 95% RH（no condensation）
Input Voltage: 5~36VDC or 9~50VDC
Working Current: ~200mA
Power: Certifications: FCC/CE/RoHS
Warranty: 1 year
Accessories: 1* Power Adapter 1* Serial Cable 1* Ethernet Cable 1* WiFi Antenna
