CXSM10-40 CXSM10 – 40 CXSM Dual Rod Pneumatic Guided Cylinder KK29

CXSM10-40 CXSM10 – 40 CXSM Dual Rod Pneumatic Guided Cylinder KK29

Description:

Actuator,Cylinder,Dual Rod,Bore 20mm,Stroke 50mm,Port M5x0.8,Double Acting,CXSM

SMC Dual-Rod Cylinders with slide bearings (CXSM type) or ball bearing slides (CXSL type), suitable for ‘pick-and-place’ applications, operating with non-lubricated, filtered, compressed air. Dual-Rod Cylinders feature high non-rotational accuracy, dual port locations, and standard magnetic sensing and buffer cushioning. Integral stroke adjustment may be set to standard stroke less 5mm. The cylinders incorporate a recess for auto switches, and may be used in operating environments from 5 to 60°C.

Feature:

Manufacturer Series CXS

Bore 10mm

Stroke 40mm

Maximum Operating Pressure 0.7 MPa

Cushioning Type Rubber

Dimensions 112 x 46 x 17mm

Weight 210g

Maximum Operating Temperature +60°C

Length 112mm

Width 46mm

Height 17mm

Minimum Operating Temperature -10°C
