DM556D Nema17 Nema23 5.6A 20 to 50VDC Stepper Motor Driver KM98

DM556D Nema17 Nema23 5.6A 20 to 50VDC Stepper Motor Driver KM98

Description:
The DM556D is a new generation high-performance digital stepper driver based on DSP with advanced control algorithm. The motors driven by DM 556D can run with much smaller noise and much less vibration than other drivers in the market. The DM556D possess the feature of lower noise, lower vibration, and lower heating. The DM556D’s voltage is DC 24V-50V. It is suitable for all the 2-phase hybrid stepper motor whose current is less than 5.6A.There are 16 kinds of microstep of DM556D.
The maximum step number of DM 556D is 51200 steps/rev (microstep is 1/256 ). Its current range is 2.1A-5.6A, and its output current has 8 stalls. DM556D has automatic semi-flow, over-voltage, under voltage and over-current protection function.

Feature:
Model: DM556D
Rated voltage: 48(V)
Speed response frequency: 20 (KHz)
Applicable motor: 2-phase stepping motor of current< 5.6A
Size: 12 x 8.8cm / 4.72 x 3.46in

Package included:
1 x Step Motor Drive
