VTE18-4N4712 VTE184N4712 VTE18 4N4712 NPN Proximity sensor PO78

VTE18-4N4712 VTE184N4712 VTE18 4N4712 NPN Proximity sensor PO78

Decription:
otoelectric Proximity Switch, Energetictype, IR, sr: 400mm; VTE18-4N4712
Cylindrical M18 housing
Three sensing distances of 200 mm, 400 mm or 800 mm

Feature:
Sensor/ detection principle Photoelectric proximity sensor, energetic
Housing design (light emission) Cylindrical
Housing length 63.6 mm
Thread diameter (housing) M18 x 1
Optical axis Axial
Sensing range max. 5 mm … 400 mm 1)
Sensing range 5 mm … 350 mm
Type of light Infrared light
Light source LED 2)
Light spot size (distance) ? 20 mm (400 mm)
Angle of dispersion Approx. 2.8°
Adjustment Potentiometer, 270° (Sensing range)

MECHANICS/ELECTRONICS
Supply voltage 10 V DC … 30 V DC 1)
Ripple = 10 % 2)
Power consumption 30 mA 3)
Switching output NPN 4)
Switching mode Light/dark switching 4)
Switching mode selector Selectable via L/D control cable
Output current Imax. 100 mA
Response time = 2 ms 5)
Switching frequency 250 Hz 6)
Connection type Cable, 4-wire, 2 m 7)
Cable material PVC
Conductor cross-section 0.14 mm?
Cable diameter ? 5 mm
Circuit protection
