NBN40-U1-E2 NBN40 U1 E2 PNP NO DC Inductive sensor Proximity PZ84

NBN40-U1-E2 NBN40 U1 E2 PNP NO DC Inductive sensor Proximity PZ84

Feature:
Sensor head bidirectional and rotatable
40 mm non-flush
3-wire DC
4 LEDs indicator for 360° visibility
Switching function Normally open (NO)
Output type PNP
Rated operating distance 40 mm
Installation non-flush
Output polarity DC
Assured operating distance 0 … 32.4 mm
Actual operating distance 36 … 44 mm
Reduction factor rAl 0.31
Reduction factor rCu 0.3
Reduction factor r304 0.74
Reduction factor rBrass 0.39
Output type 3-wire

Add to Watch List

Inductive sensor NBN40-U1-E2
Sensor head bidirectional and rotatable
40 mm non-flush
3-wire DC
4 LEDs indicator for 360° visibility

Technical Data

Documents

CAD+CAE

Approvals+Certificates

Associated Products

FAQ/Knowledge Base
Please note: All product-related documents, such as certificates, declarations of conformity, etc., which were issued prior to the conversion under the name Pepperl+Fuchs GmbH or Pepperl+Fuchs AG, also apply to Pepperl+Fuchs SE.

Download the complete datasheet as a PDF:ENG
Datasheet excerpt: Technical data of NBN40-U1-E2
General specifications
Switching function Normally open (NO)
Output type PNP
Rated operating distance 40 mm
Installation non-flush
Output polarity DC
Assured operating distance 0 … 32.4 mm
Actual operating distance 36 … 44 mm
Reduction factor rAl 0.31
Reduction factor rCu 0.3
Reduction factor r304 0.74
Reduction factor rBrass 0.39
Output type 3-wire
Nominal ratings
Operating voltage 10 … 30 V DC
Switching frequency 0 … 180 Hz
Hysteresis typ. 5 %
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop ≤ 2 V
Operating current 0 … 200 mA
Off-state current 0 … 0.5 mA typ. 0.01 mA
No-load supply current ≤ 20 mA
Time delay before availability 80 ms
Operating voltage indicator LED, green
Switching state indicator LED, yellow
