IM08-04NPS-ZTK IM08 04NPS ZTK M8 Inductive proximity sensor PZ02

IM08-04NPS-ZTK IM08 04NPS ZTK M8 Inductive proximity sensor PZ02

Description:
IM08-04NPS-ZTK INDUCTIVE SENSOR, M8, 4MM RANGE NON FLUSH, PNP NO, M8 3 PIN CONNECTOR

Feature:
Housing: Cylindrical
Thread size: M8 x 1
Sensing range Sn: 4 mm
Installation type: Non-flush
Switching frequency: 2,500 Hz
Output type: PNP
Output function: NO
Electrical wiring: DC 3-wire
Enclosure rating: IP 67 1)
Connection type: Connector M8, 3-pin
Housing: Short-body
Supply voltage: 10 V DC … 30 V DC
Ripple: ≤ 10 % 1)
Voltage drop: ≤ 1.2 V 2)
Power consumption: ≤ 10 mA 3)
Time delay before availability: ≤ 5 ms
Hysteresis: 1 % … 20 %
Repeatability: ≤ 5 % 4) 5)
Temperature drift (of Sr): ± 10 %
EMC: According to EN 60947-5-2
Output current Ia: ≤ 200 mA
