E2EQ-X4X1 E2EQ – X4X1 M12 4MM DC 2Wires NO Proximity Sensor SH67

E2EQ-X4X1 E2EQ – X4X1 M12 4MM DC 2Wires NO Proximity Sensor SH67

Description:
Shielded, Cylinder type (with screw) M12, DC 2-wire models, Sensing distance 4 mm ±10%, NO, No polarity, Pre-wired models (2 m)

Feature:
Sensing head size M12
Type Cylinder type (with screw), Shielded
Power source DC 2-wire models
Sensing distance 4 mm ±10%
Setting distance 0 to 3.2 mm
Differential distance 15% max. of sensing distance
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals.)
Standard sensing object Iron 12 x 12 x 1 mm
Response frequency 1 kHz (Average value)
Power supply voltage 12 to 24 VDC ripple (p-p) 10% max.
Operating voltage range 10 to 30 VDC
Leakage current 0.8 mA max.
Control output (Switching capacity) 3 to 100 mA
Control output (Residual voltage) 5 V max. (Load current 100 mA with cable length of 2 m)
Indicator Operation indicator (red), Operation setting indicator (green)
Operation mode NO
Polarity No polarity
Protective circuit Output short-cut protection Surge suppressor
