Bi5-M18-AN6X 5mm NPN NO Embedded Inductive Sensor SU75

Bi5-M18-AN6X 5mm NPN NO Embedded Inductive Sensor SU75

Featire:
Product type: inductive sensor
Installation method: embedded
Output mode: NPN
Switching function: Normally Open (NO)
Detection distance(mm): 5mm
Assured operating distance(mm): 0-4mm
Installation: flush
Output polarity: DC
Reduction factor rAl: 0.39
Reduction factor rCu: 0.35
Reduction factor r304: 0.75
Reduction factor rBrass: 0.49
Output type: 3-wire
Operating voltage: 10…30 V
Switching frequency: 0…500 Hz
Hysteresis: typ. 5%
Reverse polarity protection: reverse polarity protected
Short-circuit protection: pulsing
Voltage drop: ≤ 3V
Operating current: 0…200 mA
Off-state current: 0…0.5 mA typ. 0.1?A at 25℃
No-load supply current: ≤15 mA
Switching state indicator: LED, yellow
Ambient temperature: -25 … 70℃(-13…158℉)
Connection type: cable PVC, 2m
Core cross-section：0.14mm?
Housing material: brass, nickel-plated
Sensing face: PBT
Protection level: IP67
