MDR-60-24 24V 2.5A 60W AC DC Industrial DIN Rail Power Supply
Rp260,000.00
VOUCHER
Diskon 5% min. belanja Rp1JT
🔥 7 items sold in last 3 jam
76 orang sedang melihat produk ini sekarang
Tanya dulu via WhatsApp
DAPPRA MDR-60-24 (SKU: OE87) is a 60W single output ultra-slim industrial DIN rail power supply with 24V DC / 2.5A output and universal 85–264 VAC input. Slim plastic housing, fanless natural convection cooling, complete protection functions, ideal for industrial control and automation.
Share:
Overview
MDR-60-24 Overview
The DAPPRA MDR-60-24 (SKU: OE87) is the 24V model in the 60W MDR tier. It provides 24V DC at 2.5A from a universal 85–264 VAC input in a 40 mm blue plastic housing, bridging the gap between the MDR-60-12 (5A at 12V) and the MDR-100-24 (4A at 24V).
It is suited to 24V sensor clusters, relay banks and small solenoid groups whose combined draw stays within 2.5A. The MDR-60-24 includes a dry DC OK relay contact (30V/1A), 24–30V +V ADJ, hiccup-mode overload protection and over-voltage shutdown (30–36V). Efficiency is 87%, the highest in the 60W tier, and the unit is certified for Class I Division 2 T4 hazardous locations.
Key Features
MDR-60-24 Key Features
- 60W · 24V / 2.5A24V DC at 2.5A, +V ADJ 24–30V.
- DC OK Relay ContactDry contact 30V/1A on TB2 pins 5–6.
- 40 mm HousingBlue plastic, 40 × 90 × 100 mm.
- Efficiency 87%Highest in the 60W tier.
- Class I, Div 2 T4Hazardous-location certification.
- Overload 105–150%Hiccup-mode auto-recovery.
- Over-Voltage 30–36VShutdown and re-power.
Specifications
MDR-60-24 Specifications
Output
| DC Voltage | 24V |
| Current | 2.5A |
| Power | 60W |
| Ripple | 150mVp-p |
| Adjustment | 24–30V |
Input
| Voltage | 85–264VAC · 120–370VDC |
| Efficiency | 87% |
| No-Load | <0.75W |
Protection
| Overload | 105–150% · Auto-recovery |
| Over Voltage | 30–36V · Shutdown |
Notes24–30V adjustable. DC OK relay contact. Div 2 T4.
Dimensions
MDR-60-24 Dimensions
Mechanical
| Width | 40 mm |
| Height | 90 mm |
| Depth | 100 mm |
| Weight | ~0.30 kg |
Clearances
| Top/Bottom | 40 / 20 mm |
| Sides | 5 mm |
| DIN Rail | TS35/7.5 or 15 |
Installation
MDR-60-24 Installation
01 / 06
Vertical Only
Input bottom, output top.
02 / 06
Clearances
5 mm sides, 40 mm top, 20 mm bottom.
03 / 06
TS35 Rail
TS35/7.5 or 15.
04 / 06
FG to PE
Frame ground to earth.
05 / 06
Temperature
−20 to +70°C, derate above 50°C.
06 / 06
Div 2 T4
Verify hazardous-location certificate.
Wiring
MDR-60-24 Wiring
TB1
| Pin | Assignment |
|---|---|
| 1 | FG |
| 2 | AC/N |
| 3 | AC/L |
TB2 (6 Pins)
| Pin | Assignment |
|---|---|
| 1,2 | +V |
| 3,4 | −V |
| 5,6 | DC OK relay contact |
DC Output24–30V adjustable. DC OK is a dry relay contact.
Safety
MDR-60-24 Safety & Cautions
- Qualified technician only.
- Do not connect primary and secondary.
- Burn hazard.
- Protect openings.
- FG to PE.
- Do not exceed 2.5A / 60W.
- Do not use DC OK as power output.
- Disconnect before maintenance.
Applications
MDR-60-24 Industrial Applications
24V Sensors
Relay Banks
24V Solenoids
PLC I/O
Hazardous Locations
Machine Control
Building Automation
Process Control
Next Step
Need the MDR-60-24?
Contact DAPPRA Automation — or explore the full MDR Series.
Support
MDR-60-24 FAQ
What is the DAPPRA MDR-60-24?
The DAPPRA MDR-60-24 (SKU: OE87) is a 60W single-output industrial DIN rail power supply providing 24V DC at 2.5A from a universal 85–264VAC input, in a 40 mm blue plastic housing with fanless cooling, DC OK relay contact and 24–30V +V ADJ.
How does the MDR-60-24 differ from the MDR-60-12?
Both deliver 60W in the same 40 mm housing, but the 24V model provides 2.5A while the 12V model provides 5A. Choose by load voltage: 24V loads use the MDR-60-24; 12V loads use the MDR-60-12. They are not interchangeable.
Can the MDR-60-24 power several 24V sensors and relays?
Yes, provided the combined steady-state current of the sensors and relay coils stays within 2.5A (60W). Account for relay pull-in current, which can be higher than holding current. If the combined load exceeds 2.5A, step up to the MDR-100-24 (4A).
What is the output voltage adjustment range of the MDR-60-24?
24–30V via the +V ADJ potentiometer. Verify that all connected 24V devices tolerate the higher voltage before turning it up; most industrial 24V devices accept 26.4V, but check each datasheet.
What is the over-voltage protection threshold of the MDR-60-24?
Over-voltage protection triggers at 30–36V. The output shuts down and requires re-powering to recover.
What is the typical efficiency of the MDR-60-24?
The MDR-60-24 achieves 87% typical efficiency at 230VAC input and full load, the highest among the 60W MDR models (MDR-60-5: 78%; MDR-60-12: 85%; MDR-60-48: 87%).
What is the input voltage range of the MDR-60-24?
85–264VAC single phase (47–63Hz) or 120–370VDC. Do not connect directly to 380VAC three-phase.
What protection functions does the MDR-60-24 include?
Short-circuit protection, overload protection (above 105%, hiccup mode auto-recovery) and over-voltage protection (30–36V, shutdown and re-power).
Does the MDR-60-24 have a DC OK relay contact?
Yes. TB2 pins 5 and 6 provide a dry DC OK relay contact rated 30V/1A resistive, suitable for PLC input.
What are the dimensions and weight of the MDR-60-24?
40 × 90 × 100 mm (W × H × D), approximately 0.30 kg.
What is the terminal pin assignment of the MDR-60-24?
TB1: Pin 1 = FG, Pin 2 = AC/N, Pin 3 = AC/L. TB2 (6 pins): Pins 1,2 = +V; Pins 3,4 = −V; Pins 5,6 = DC OK relay contact.
Can the MDR-60-24 drive a 24V solenoid?
A 24V solenoid can be powered if its steady-state current plus inrush stays within 2.5A. Add a flyback diode across the coil to suppress the inductive kick, and verify that the inrush duration does not exceed the hiccup overload response time.
What is the ripple and noise of the MDR-60-24?
Maximum 150mVp-p, measured at 20MHz bandwidth with a 0.1μF and 47μF parallel capacitor.
Can the MDR-60-24 be used in a hazardous location?
The MDR-60 series is certified for Class I, Division 2 T4 hazardous locations. Confirm the certificate and model coverage for your specific site classification before installation.
What certifications does the MDR-60-24 have?
UL508, UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004, BSMI CNS14336-1 and AS/NZS 60950.1, plus Class I Division 2 T4 (confirm certificate coverage).
