RS-24V/2S RS-24V / 2S analog 4-20mA surge protection device SR53

RS-24V/2S RS-24V / 2S analog 4-20mA surge protection device SR53

Description:
The RS-24/2S 4-20mA analog surge protector is commonly used in lightning and surge protection control systems on signal lines.
The device operates in an environment of -40 o C ~ 80 o C, humidity below 90% (25 o C)

Feature:
Rated current signal voltage (U N ): 24V-
Maximum continuous working voltage (UC ) : 30V-
Maximum operating current (I L ): 1 A
Nominal discharge current (8/20µs) (I n ): 5 kA
Maximum discharge current (8/20µs) (I max ):10 kA
Protection level (1kV/µs) (U p ): ≤ 60V
Response time (t A ): ≤ 25ns
Impedance (IL): ≤ 0.3dB ( 0 ~ 10MHz)
Frequency (f G ): 10MHz
Wire specifications: 0.5mm 2 ~ 2.5mm 2
Shell material: Fireproof plastic
Operating temperature: -40 o C ~ 80 o C
