E50S8-600-3-T-24 E50S8 600 3 T 24 600P/R Rotary Encoder OH35
Rp650,000.00
Tanya dulu via WhatsApp
E50S8-600-3-T-24 E50S8 600 3 T 24 600P/R Rotary Encoder OH35 Feature: Shaft outer diameter ?8mm Max. response frequency 300kHz Max. allowable revolution 5000rpm Starting torque Max. 70gf.cm(max. 0.00686N.m) Resolution 600P/R Output phase A, B, Z Control output Totem pole Power supply 12-24VDC ±5%(ripple P-P: max. 5%) Connection type Axial cable type Protection structure IP50 Approval Environment_Ambient temperature -10 to 70℃, storage: -25 to 85℃ Environment_Ambient humidity 35 to 85% RH, storage: 35 to 90% RH Accessories ?8mm coupling, Bracket
