3 Axis Mach3 CNC USB Motion Controller Card 200KHz Stepper Servo KA03

Features
Support all the Mach3 versions.
Plug-and-Play on all Windows system.
Support for USB hot swapping . To monitor USB attachment state any time. While Mach3 are working, if you uproot USB cable, then plug it also can make it work at once.
Support 3 Axis linkages as well as 4 shaft linkage.
Maximum output 200 KHz step-pulse frequency .
There are 8 super-speed 10 MHz opto-couplers, 24 General opto-couplers, so the total amounts of opto-couplers are up to 34. Isolate all the input/output.
Have on-board isolation power supply, NO external power supply.
Support Automatic tool-setting, electronic hand wheel, software limit, software backlash .
Speed: 48M, Real-time input signal without PC intervention.
Have status indicator to indicate Mach3 attachment, and USB connectivity.
Have 16 input indicators.
Have Speed-measurement function.

Applications:
Suitable for all stepper and sevro drivers.

Note:This breakout board is just a interface board, NOT a stepper driver board, it must work together with the microstep drivers(eg. MA860H etc..) to control the stepper motors. So, it CANNOT control the stepper motors solely.

Package Including:
1pcs 3 Axis Mach3 USB Motion Control Card
1pcs High quality USB Cale with magnet righs
