1.5Kw 220V 2HP Spindle Motor Speed Controller VFD inverter CNC AW30

1.5Kw 220V 2HP Spindle Motor Speed Controller VFD inverter CNC AW30

Feature:
Rated input: Single phase 220V 50-60Hz
Rated output: three phase 220V 7A 0-1000HZ
Rated output power: 1.5KW
This converter is special for spindle motor,

SPEK:
1.Range: 0.0~1000.00Hz

2.Other functions: Lower limit frequency, start frequency, frequency of parking, three jumping frequency can be set respectively

3.Precision: Digital: 0.01% (10 ~ 40 centigrade degree ); Analog: 0.1% (25±10 centigrade degree)

4.Keyboard set way: 0.01 Hz can be directly to setting by up and down.

5. Analog set way: external voltage 0 to 5V, 0 to 10 V, 4-20 mA, 0 to 20 mA

General control:

1.Multifunctional output: relay output, open-collector output, implementation of operating the indication and alarm of zero velocity, counter, external anomalies, program operation etc.

2.Other functions: automatic voltage regulator (AVR), slow or freedom stop, dc brake, automatic reset then start again, frequency tracking, PLC program control, moving around control, carrier is adjustable, up to 16 KHZ, etc.

3. ACC/DEC control: 4 ACC/DEC time (0.1-6500 seconds) arbitrary choice.

4.V/F curve: can be arbitrarily set V/F curve

5.Torque control: can set torque increasing, the largest launch torque can be up to 150% in 1.0 Hz

6.Multi-function input: 6 multi-function input, 8 period of speed control, the program runs, 4 period of ACC/DEC switch, up and down function, counters, external abrupt stop, and other functions.

Defensive function:

1.Instantaneous power outage restart: after instantaneous stop can restart by frequency tracking way.

2. Stall prevent: stall prevention of ACC/DEC operation.

3. Output short circuit: circuit protection

4. Protection functions: return flow, over-voltage, under-voltage, overload, overheating, voltage prevents stall, current prevents stall etc.

5. Other features: reverse restrictions, directly start and fault reset function after booting, lock parameters
