Nema 34 8.5N.m 86 Hybrid Stepper Servo Motor 8.5Nm HSS86H Driver KM96
Rp2,500,000.00
VOUCHER
Diskon 5% min. belanja Rp1JT
🔥 8 items sold in last 3 jam
42 orang sedang melihat produk ini sekarang
Tanya dulu via WhatsApp
Nema 34 8.5N.m 86 Hybrid Stepper Servo Motor 8.5Nm HSS86H Driver KM96
Description:
This is the nema 34 series hybrid stepper servo kit. The HSS86H driver adopts new generation 32 bit DSP and vector control technology, which can avoid the stepper motor losing steps and ensure the accuracy of the motor.
The torque reducing is much lower than open loop stepper motor when it is at higher speed. The high speed performance and torque are enhanced in a great extent. Meanwhile the current control is based on the load, that can reduce the motor temperature rising effectively, then can extend the using life of the motor.
The build-in place in position and alarm output signal can help the upper monitor to monitor and control. The function of position ultra difference alarm can ensure the machine work safely. The closed loop system is an ideal improvement and a good replacement of open loop system,besides that,it also have some function of AC servo motors.
Feature:
Nema34 Closed loop servo motor 8.5N.m
Size:86x86x137mm
Current :5.8A
Phase:2
Step Angle(degrees):1.8 degree
Lead wire:4pcs
Holding Torque:8N.m
Resistance:0.44±10%Ω
Inductance:3.7±20%mH
Insulation resistance:100MOhm(500V DC)
Insulation Class:B
HSS86H Hybrid Servo Motor Driver Controller
Voltage range: AC24-70V or DC30-100V
Peak current :Peak 8.0A
Logic input current:7-20mA
Frequency:0-200KHz
Suitable motor: 86HSE154,86HSE116, 86HSE82
Encoder lines:1000
Insulation resistance:>=500MΩ
Operating temprature:0~50℃
Operating humidit:40~90%RH
Virbration:5.9m/s2Max
