0.28N 0.28 N.M 0.28 NM NEMA 17 42 Stepper motor TB6600 drive kit KO04

Feature:
Stepper motor:
Current: 1.3A
Voltage:12V
Output torque: 0.28Nm (Nm)
Most popular model equipped with 1.8 degree step angle
Specially designed and suitable for 3D Printers
Low noise and big torque and high quality
Bipolar 4-wire: Black A +, Green A-, Red B +, Blue B-
It has a quite stable performance during work and will not loss step

TB660 Stepper motor driver:
TB6600 Arduino stepper motor driver has a wide range of power input, 9~42VDC power supply. And it is able to output 4A peak current, which is enough for the most of stepper motors. The stepper driver supports speed and direction control.You can set its micro step and output current with 6 DIP switch. There are 7 kinds of micro steps (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 kinds of current control (0.5A, 1A, 1.5A, 2A, 2.5A, 2.8A, 3.0A, 3.5A) in all. And all signal terminals adopt high-speed optocoupler isolation, enhancing its anti-high-frequency interference ability. As a professional device, it is able to drive 57, 42-type two-phase, four-phase, hybrid stepper motor.
