PR30-15DN2 M30 15mm NPN NC Inductive Proximity Sensor OF28

PR30-15DN2 M30 15mm NPN NC Inductive Proximity Sensor OF28

Description:
Proximity Sensor, 15mm Sensing, M30 Round, Non-Shielded, NPN NC, 3 Wire, 2m cable, 10-30 VDC

Feature:
Tipe kabel dan daya Tipe DC 3-wire 12-24VDC
Diameter sisi sensing M30
Jarak deteksi 15 mm
Instalasi Non-flush
Target sensing standar 45×45×1mm(iron)
Frekuensi respon 200Hz
spesifikasi arus Konsumsi arus: Maks. 10mA
Output kontrol NPN Normally Closed
Material Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side ? 8 mm: SUS303),
washer: Nikel plated Iron, sensing side: polybutylene terephthalate,
standard cable (black): polyvinyl chloride (PVC),
oil resistant cable (gray): oil resistant polyvinyl chloride (PVC)
Material/ standar kabel Kabel standar
Tingkat proteksi IP67(standar IEC)
Panjang bodi Tipe standar
