EV 112M EV112M EV-112M M12 EV Series proximity sensor PW72

EV-112M EV 112M EV112M M12 EV Series proximity sensor PW72

Feature:
EV-112M

wo-wire self contained amplifier proximity sensors

EV series

EV-112MSO(2062)

Type: Shielded

Shape: M12

Detecting distance: 2.5 mm ±10%

Detectable object: Ferrous metals (see Characteristics for nonferrous metals)

Standard target
(iron, t=1 mm): 12 x 12 mm

Hysteresis: 10% max. of detecting distance

Response frequency: 600 Hz

Operation mode: N.O.

Temperature characteristics: ±10% max. of detecting distance at +23°C, within -25 to +70°C

Control output
(switching capacity): 5 to 200 mA

Protection circuit: Reversed polarity, short-circuit, surge voltage

Cable length: 500 mm

Rating: Power voltage: 12 to 24 VDC

Current consumption (leakage
current): Current consumption (leakage current): 1.0 mA max., Residual voltage: 3.6 V max. (with 2-m cable)

Residual voltage: Residual voltage: 3.6 V max. (with 2-m cable)
