QY40P 16 Point Transistor Digital Output Module PS31

QY40P 16 Point Transistor Digital Output Module PS31 Feature: Product No : QY40P Product Type : Transistor Output Module (Sink Type) Number of output points : 16 point Isolation method : Photocoupler Rated load voltage : 12-24VDC (+20/-15%) Maximum load current : 0.1A/point, 1.6A/common Maximum inrush current : 0.7A, 10ms or less Leakage current at OFF : 0.1mA or less Maximum voltage drop at ON : 0.1VDC (TYP.) 0.1A, 0.2VDC (MAX.) 0.1A Surge suppressor : Zener diode Dielectric withstand voltage : 560VAC rms/3 cycles (altitude 2000m) Insulation resistance : 10M? or more by insulation resistance tester Protection degree : IP2X Common terminal arrangement : 16 points/common (common terminal: TB18) Number of occupied I/O points : 16 points (I/O assignment is set as a 16-point output module.) Operation indicator : ON indication (LED) External connections : 18-point terminal block (M3 6 screws) Applicable wire size : 0.3 to 0.75mm2 core (2.8mm OD max.) Applicable crimping terminal : R1.25-3 (Sleeved crimping terminals cannot be used.) Internal current consumption (5VDC) : 65mA (TYP. all points ON) (0.07A is shown on the rating plate of the module.)
