SY7120-3DZ-02 AC110V Air Control Valve 4-Way 1 Solenoids Number Of Positions KP97

SY7120-3DZ-02 AC110V Air Control Valve 4-Way 1 Solenoids Number Of Positions KP97

Feature:
SY7120-3DZ-02 – Air Control Valve – Body Ported Subplate Included, 4-Way, 1 Solenoids, Number of Positions 2, 110/115 V ac Supply Voltage, DIN Terminal, 0.81 (A/B to EA/EB) C, 0.93
number of ports: 5

piping type: Body Ported Subplate Included
operating pressure range: +0.15 to +0.7 Mpa
flow direction: 4-Way
response time: 38 ms
number of solenoids: 1
operating temperature range: -10 to +50 °C
number of positions: 2
solenoid power consumption: 1.07 (ac) W
solenoid supply voltage: 110/115 V ac
valve function: Spool
solenoid electrical entry: DIN Terminal
solenoid allowable voltage fluctuation: -10 to +10 %
flow coefficient (cv) / flow factor (kv): 0.81 (A/B to EA/EB) C, 0.93 (P to A/B) C
body material: Aluminum
port type: 1/4 BSPT
seal material: Rubber
manual operation type: Non-Locking Push Type (Flush)
standards met: JIS, JIS B 8375-1981, IEC 60529
actuation: Piloted Solenoid
operating medium: Air
