ACS606 Brushless Servo Motor Drive Digital AC Servo Drive KP61

ACS606 Brushless Servo Motor Drive Digital AC Servo Drive KP61

Description:
Leadshine’s fully digital AC servo drive ACS606 is developed with 32-bit DSP based on advanced control algorithm. Since its input commands are PUL/DIR signals, the users can upgrade stepping drives to the ACS606 without changing control systems. The ACS606 can offer high precision, high speed and high reliability performance, and widely used in inkjet printers, engraving machines, and etc. A built-in controller can be used for testing and tuning. PC based and handheld configuration & tuning tools can meet different tuning environments or requirements. Use lead LSK-001 and ProTuner software to tune the drive.

The ACS606 can drive both DC brush-less and AC servo motors.But it is more suitable for the DC brush-less servo motors. Compare to the ACS806, the ACS606 has less I/O, thus has smaller size and higher cost-effective.

Features:

FOC-SVPWM technologies
PC based and handheld configuration tools
Self-test function with trapezoidal velocity profile
Support PUL/DIR and CW/CCW control signals
Opto-isolated, support single-ended and differential inputs
Following error lock range adjustable
Over-voltage, over-current, encoder failure protections
10 latest failures self-record function
